AMD Radeon RX580 8 GB GDDR5 (Sapphire Nitro RX 580)
Officially recommended card for macOS Mojave now with EFI boot screen!
System requirements:
- Apple Mac Pro 3,1 (2008), Apple Mac Pro 4,1 (2009) or Mac Pro 5,1 (2010-2012)
- installed macOS 10.13.4 (High Sierra) or newer
- native support by macOS High Sierra, Mojave, Catalina, Big Sur, Monterey, Ventura, no drivers needed
Key features:
- compatible with macOS and Windows (via BootCamp)
- supports Apple boot screen (gray screen with Apple logo on startup) on all ports (also on 4K displays)
- uses internal Mac Pro power supply
- supports PCI Express 2.0 link under macOS and Windows
- supports five displays simultaneously: 1x dual-link DVI + 2x DisplayPort 1.4 + 2x HDMI 1.4 (2.0 under Windows)
- supports 4K/5K@60Hz via DisplayPort and 4K@30Hz HDMI/DVI ports (HDMI 4K@60 Hz possible via active DisplayPort to HDMI 2.0 adapter)
- supports OpenGL, OpenCL and Metal in applications and games
- allows an upgrade to macOS Mojave, Catalina, Big Sur, Monterey and Ventura
- allows Windows 8/8.1/10/11 installation in UEFI mode with sleep/resume working
- supports sound via HDMI and DisplayPorts under macOS (from macOS 10.14 or above)
Technical specification:
- graphics processor clock: 1411 MHz
- memory speed: 2000 MHz
- amount and type of memory: 8 GB GDDR5
- bus width: 256-bit
- bus: PCI-Express 2.0 x16 (5.0 GT/s)
- TDP: 185W
Boot screen
- up to 4K@60Hz via DisplayPort, up to 4K@30Hz via HDMI, up to 4K@30Hz via DVI
Condition
- Used (flashed)
- 12 months
Package includes
- 6-pin Mac Pro PCIe power cable, 8-pin Mac Pro PCIe power cable
Specification
- 1x DVI dual-link, 3x DisplayPort 1.4, 1x HDMI 2.0 (1.4 under macOS)
- up to 5 concurrent displays
- 1411 MHz
- 2000 MHz
- 8 GB GDDR5
- 256-bit
- PCI-Express 2.0 x16 (5.0 GT/s)
- not supported
- 6-pin + 8-pin
- 185 W
- HDMI Audio, DisplayPort Audio
- Metal, OpenCL, OpenGL
System Requirements
- 3,1 (2008), 4,1 (2009), 5,1 (2010-2012)
- 10.13.4 (High Sierra) or later, 10.14 (Mojave) or later, 10.15 (Catalina) or later, 11.0.1 (Big Sur) or later, 12.0.1 (Monterey) or later, 13.0 (Ventura) or later
- Not needed
- Yes, via Apple BootCamp (also in UEFI mode)
