AMD Radeon RX580 8 GB GDDR5 (Sapphire Nitro RX 580)

€269.00 €339.00

Officially recommended card for macOS Mojave now with EFI boot screen!



System requirements:

- Apple Mac Pro 3,1 (2008), Apple Mac Pro 4,1 (2009) or Mac Pro 5,1 (2010-2012)
- installed macOS 10.13.4 (High Sierra) or newer
- native support by macOS High Sierra, Mojave, Catalina, Big Sur, Monterey, Ventura, no drivers needed



Key features:

- compatible with macOS and Windows (via BootCamp)
- supports Apple boot screen (gray screen with Apple logo on startup) on all ports (also on 4K displays)
- uses internal Mac Pro power supply
- supports PCI Express 2.0 link under macOS and Windows
- supports five displays simultaneously: 1x dual-link DVI + 2x DisplayPort 1.4 + 2x HDMI 1.4 (2.0 under Windows)
- supports 4K/5K@60Hz via DisplayPort and 4K@30Hz HDMI/DVI ports (HDMI 4K@60 Hz possible via active DisplayPort to HDMI 2.0 adapter)
- supports OpenGL, OpenCL and Metal in applications and games
- allows an upgrade to macOS Mojave, Catalina, Big Sur, Monterey and Ventura
- allows Windows 8/8.1/10/11 installation in UEFI mode with sleep/resume working
- supports sound via HDMI and DisplayPorts under macOS (from macOS 10.14 or above)



Technical specification:

- graphics processor clock: 1411 MHz
- memory speed: 2000 MHz
- amount and type of memory: 8 GB GDDR5
- bus width: 256-bit
- bus: PCI-Express 2.0 x16 (5.0 GT/s)
- TDP: 185W



https://pics.macvidcards.eu/rx580_8gb_sapphire/rx580.jpg


https://pics.macvidcards.eu/rx580_8gb_sapphire/2.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire/3.jpg

https://pics.macvidcards.eu/r9_280_3gb_xfx/hdmi_audio.jpg

https://pics.macvidcards.eu/r9_280_3gb_xfx/dp_audio.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire/4.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire/4.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/nowe/1.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/nowe/2.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/nowe/3.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/nowe/4.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/nowe/5.jpg

https://pics.macvidcards.eu/rx580_8gb_sapphire2/8.jpg
Boot screen
  • up to 4K@60Hz via DisplayPort, up to 4K@30Hz via HDMI, up to 4K@30Hz via DVI
Condition
  • Used (flashed)
  • 12 months
Package includes
  • 6-pin Mac Pro PCIe power cable, 8-pin Mac Pro PCIe power cable
Specification
  • 1x DVI dual-link, 3x DisplayPort 1.4, 1x HDMI 2.0 (1.4 under macOS)
  • up to 5 concurrent displays
  • 1411 MHz
  • 2000 MHz
  • 8 GB GDDR5
  • 256-bit
  • PCI-Express 2.0 x16 (5.0 GT/s)
  • not supported
  • 6-pin + 8-pin
  • 185 W
  • HDMI Audio, DisplayPort Audio
  • Metal, OpenCL, OpenGL
System Requirements
  • 3,1 (2008), 4,1 (2009), 5,1 (2010-2012)
  • 10.13.4 (High Sierra) or later, 10.14 (Mojave) or later, 10.15 (Catalina) or later, 11.0.1 (Big Sur) or later, 12.0.1 (Monterey) or later, 13.0 (Ventura) or later
  • Not needed
  • Yes, via Apple BootCamp (also in UEFI mode)
