AMD Radeon RX480 8 GB GDDR5 (reference AMD RX 480)

Out of stock
€219.00 €289.00

AMD Radeon RX480 with twice as RAM. Same great Polaris chip as RX580 just older name.



Very rare - reference AMD version 2-slot wide with a single 6-pin power connector so you can use a pair of these or use free 6-pin power for other PCIe cards requiring extra power connector.



Works great under macOS Mojave/Catalina/Big Sur/Monterey/Ventura and the latest Sonoma. Now with EFI boot screen.



System requirements:

- Apple Mac Pro 3,1 (2008) or Apple Mac Pro 4,1 (2009) or Apple Mac Pro 5,1 (2010-2012)
- installed macOS 10.13.4 (High Sierra) or newer
- native support by macOS High Sierra, Mojave, Catalina, Big Sur, Monterey and Ventura, Sonoma via patcher, no drivers needed



Key features:

- compatible with macOS and Windows (via BootCamp)
- supports Apple boot screen (gray screen with Apple logo on startup) on all ports (also on 4K displays)
- uses internal Mac Pro power supply
- supports PCI Express 2.0 link under macOS and Windows
- supports four displays simultaneously: 3x DisplayPort 1.4 + 1x HDMI 1.4 (2.0 under Windows)
- supports 4K/5K@60Hz via DisplayPort and 4K@30Hz via HDMI port, 4K@60Hz via HDMI is possible via active DisplayPort to HDMI 2.0 adapter
- supports Metal, OpenCL and OpenGL in applications and games
- allows an upgrade to macOS Mojave, Catalina, Big Sur, Monterey, Ventura and Sonoma
- allows Windows 8/8.1/10/11 installation in UEFI mode with sleep/resume working
- supports sound via HDMI and DisplayPorts under macOS (from macOS 10.14 or above)



Technical specification:

- graphics processor clock: 1266 MHz
- memory speed: 2000 MHz
- amount and type of memory: 8 GB GDDR5
- bus width: 256-bit
- bus: PCI-Express 2.0 x16 (5.0 GT/s)
- TDP: 150W


https://pics.macvidcards.eu/rx480_8gb_amd/4_displays.jpg

https://pics.macvidcards.eu/rx480_8gb_gigabyte/nowe/3.jpg

https://pics.macvidcards.eu/rx6600xt_8gb_asus/hdmi.jpg

https://pics.macvidcards.eu/rx580_8gb_asus/boot_screen_apple.jpg


https://pics.macvidcards.eu/rx480_8gb_gigabyte/nowe/4.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/3.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/4.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/5.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/6.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/7.jpg

https://pics.macvidcards.eu/rx480_8gb_amd/8.jpg
Boot screen
  • up to 4K@60Hz via DisplayPort, up to 4K@30Hz via HDMI
Condition
  • Used (flashed)
  • 12 months
Package includes
  • 6-pin Mac Pro PCIe power cable
Specification
  • 3x DisplayPort 1.4, 1x HDMI 2.0 (1.4 under macOS)
  • up to 4 concurrent displays
  • 1266 MHz
  • 2000 MHz
  • 8 GB GDDR5
  • 256-bit
  • PCI-Express 2.0 x16 (5.0 GT/s)
  • not supported
  • 6-pin
  • 150 W
  • HDMI Audio, DisplayPort Audio
  • Metal, OpenCL, OpenGL
System Requirements
  • 3,1 (2008), 4,1 (2009), 5,1 (2010-2012)
  • 10.13 (High Sierra) or later, 10.14 (Mojave) or later, 10.12.6 (Sierra) or later, 10.15 (Catalina) or later, 11.0.1 (Big Sur) or later, 12.0.1 (Monterey) or later, 13.0 (Ventura) or later, 14.0 (Sonoma) or later
  • Not needed
  • Yes, via Apple BootCamp (also in UEFI mode)
