AMD Radeon PRO VII 16 GB HBM2 (reference AMD)

Out of stock
€389.00 €429.00

The long awaited model now available !

Comes with Mac Pro power cables to the logic board.



System requirements:

- Apple Mac Pro 4,1 (2009) or Mac Pro 5,1 (2010-2012)
- installed macOS Catalina 10.15.1 or later
- native support by macOS Catalina, Big Sur, Monterey and Ventura/Sonoma via patcher, no drivers needed



Key features:

- compatible with macOS and Windows (via BootCamp)
- supports Apple boot screen (gray screen with Apple logo on startup) on all ports (also on 4K displays)
- uses internal Mac Pro power supply (no SATA power or Pixlas mod needed!)
- supports PCI Express 2.0 x16 link under macOS and Windows
- supports six displays simultaneously: 6x miniDisplayPort 1.4
- supports 4K/5K/8K@60Hz via miniDisplayPort
- supports Metal, OpenCL and OpenGL in applications and games
- allows Windows 10/11 installation in UEFI mode with resume/standby modes working
- supports sound via DisplayPort under macOS



Technical specification:

- graphics processor clock: 1400 MHz + 1700 MHz boost
- memory speed: 1000 MHz
- amount and type of memory: 16 GB HBM 2
- bus width: 4096-bit
- bus: PCI-Express 2.0 x16
- TDP: 250W (in reality just about 225W)



WARNING ! The only disadvantage of this model is no automatic refresh on boot picker. You need to move the mouse on boot picker to uncover icons. Other than that it works perfect !



https://pics.macvidcards.eu/pro_vii_16gb_amd/boot_screen_vii.jpg


https://pics.macvidcards.eu/pro_vii_16gb_amd/2.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/3.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/4.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/5.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/6.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/7.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/8.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/9.jpg

Ultra fast 4K gaming in highest detail:

https://pics.macvidcards.eu/pro_vii_16gb_amd/tomb_vii.jpg

https://pics.macvidcards.eu/pro_vii_16gb_amd/3dmark_vii.jpg
Boot screen
  • up to 4K@60Hz via miniDisplayPort
Condition
  • Used (flashed)
  • 12 months
Package includes
  • 6-pin Mac Pro PCIe power cable, 8-pin Mac Pro PCIe power cable
Specification
  • 6x miniDisplayPort 1.4
  • up to 6 concurrent displays
  • 1400 MHz + 1700 MHz boost
  • 1000 MHz
  • 16 GB HBM2
  • 4096-bit
  • PCI-Express 2.0 x16 (5.0 GT/s)
  • not supported
  • 6-pin + 8-pin
  • 250 W
  • DisplayPort Audio
  • Metal, OpenCL, OpenGL
System Requirements
  • 4,1 (2009), 5,1 (2010-2012)
  • 10.15.1 (Catalina) or later, 11.0.1 (Big Sur) or later, 12.0.1 (Monterey) or later, 13.0 (Ventura) or later, 14.0 (Sonoma) or later
  • Not needed
  • Yes, via Apple BootCamp (also in UEFI mode)
